Document Reference No.: FT_000118
USB-COM232-PLUS1 Datasheet
Version 1.2
Clearance No.: FTDI# 76
1.2 LED Description
The USB-COM232-Plus1 uses three LEDs to indicate a valid link as well as data traffic according to the
following table:
LED Color
Yellow
Green
Red
Function
Enumerated
TxD Activity
RxD Activity
Description
ON when USB-COM-Plus is configured and ready
Flashes when data is transmitted from the USB-COM232-Plus1 to the
attached RS232 device
Flashes when data is transmitted from the attached RS232 device to the
USB-COM232-Plus1
Table 1.1 – LED Description
1.3 Block Diagram
USB B
Client
Connector
FTDI FT232R
USB Serial Bridge
RS232
Level Shifter
DE-9P
Connector
Figure 1.2 USB-COM232-Plus1 Block Diagram
1.3.1 Block description
USB B Client Connector
This connector provides the interface for connection to a USB Host or Hub port. The maximum cable
length is 5 meters, according to the USB 2.0 specification.
FTDI FT232R
The FTDI FT232R provides the USB-to-Serial conversion. Operating system device drivers are required in
order to work with the FT232R to provide the Virtual COM Port serial functionality.
RS232 Level Shifter
The RS232 level shifter converts the signals provided by the FT232R into the voltage levels required by
RS232 devices.
DE-9P Connector (Male)
The DE-9P connector is configured in an industry standard (TIA/EIA-574) pin-out to provide connection to
RS232 peripherals through standard cables. See section 3.1.2
Copyright ? 2010 Future Technology Devices International Limited
